Electrod wolfram lantan ø 1.6 mm

ATENTIE!! Pretul afisat este PE BUCATA NU PE SET!!

Electrod TIG – WIG Wolfram (Tungsten) cu cap ALBASTRU WL-20, lungime 175 mm, grosimi de 1.6 mm.

Electrod TIG – WIG de Wolfram cap albastru WL20 de 1.6 mm

• Marcaj: ALBASTRU
• Standarde: WL20; EWLa-2
• Aliaj: 1.8 – 2.2 % Oxid de Lantan & min.97.3% Wolfram
• Radioactiv: NU
• Utilizare: DC si AC
• Aliaje sudate: Otel carbon, Inox, Cupru, Titan, Nichel, Aluminiu, Magneziu
• Grosimi: 1.6 mm
• Lungime: 175 mm

SUDARE CU ALUMINIU          mm                  A (AC) Electrod

• Grosime                 1,0-1,5 20 – 50    1,6

• Grosime 2,0                          40 – 70  2,4

• Grosime 3,0                          60 – 100                  3,2

• Grosime 4,0                          90 – 130                  3,2

SUDARE CU OTEL                   mm                  A (DC)             Electrod

• Grosime 0,4 – 0,6                5 – 25                     1,6

• Grosime 0,6 – 1,0                20 – 60   1,6

• Grosime 1,5 – 2,0                40 – 100                 3,2

Grosime                                               3,0 – 4,0                80 – 140                 3,2
